Description
This Cafe 1, ShadeCharger-equipped solar picnic table. When the sun shines, power is available. Options for battery backed-up off-grid solar power. Cafe 1 is ideal for dining and coffee establishments. Solar powered 120vac outlets and standard USB outlets for each seat. With solid concrete construction, this picnic table is extremely robust and resilient to weather conditions and vandalism.
Features
-
-
- Concrete table and galvanized steel construction
- Architectural design, and a fully engineered commercial grade structure
- True off-grid solar power design that delivers dependable year round charging power even in worst case weather conditions
- A solar powered charging table with 120v(2) receptacles and USB outlets(6)
- 300W Daytime Power inverter with GCFI protection and UL listing
- A powerful 600W DC solar array
- Supports simultaneous charging of eight mobile phones
- Supports 120v charging for tablets, laptops, cameras, and other electronic devices with standard UL listed NEMA receptacles.
- 90mph wind speed rated self-ballasted concrete construction
- Low maintenance with a ten to twenty year expected service life
- Seats six comfortably with room for additional ADA compliant wheelchair seating on ends.
- Optional 1440Whr lithium battery bank and battery inverter
- Optional Bluetooth controlled speakers for mobile connection
- Optional LED table top lighting system for nighttime use
-
- Optimized system design includes complete solar charger, battery and power inverter and
-
DIMENSIONS
- Canopy height (high side): 9 ft. (adjustable)
- Canopy head clearance height (low side): 6’6”
- Table dimensions: 68″ Round”‘
- Weight: 2200lbs
- Canopy: 58.5” W x 81″ L
- Contact factory for specific shipping costs
SOLAR CHARGING SYSTEM
- Solar array capacity: 600kW DC
- Two120V traditional electrical receptacles
- Six USB charging ports
- Battery: 1.44kWhr sealed lithium
- Inverter: 300W power inverter
- Charge controller: Lithium battery charge controller
- Battery replacement cycle: ten years/3000 cycles (typical)
- All electrical and structural steel components bonding to NEC compliant earth grounding electrode (user-supplied ground rod)
SOLAR POWER SYSTEM (with battery option)
- Design autonomy: three days with little sunlight
- Design depth of discharge: 80%
- Typical daily energy production: 3,100Whr
- Design location: Jackson California
- Table and bench top material and colors
- Wifi internet option available
STRUCTURE
- Cast reinforced concrete unit
- Wind speed rating: 90 mph self-ballasted (no surface attachment required)
- Durable industrial strength construction with easy to clean surfaces
- Seats six adults comfortably on parallel seats
- Engineered pole mount system, MIG welded frame and stainless steel screws
SECURITY
- Robust ballast mount system minimizes movement
- Additional “anti-vandal” attachment options
- Robust, heavy duty steel components components
- Optional tamper resistant hardware and fasteners
WARRANTY
- One year warranty full warranty
- Two-Year power inverter warranty
- Twenty-five year warranty on solar panel power output
