ShadeCharger Solar Powered Picnic Table

$7,935.00

Description

This ShadeCharger Solar Powered  Picnic Table,  is a battery backed-up off-grid solar powered charging station for outdoor environments. Solar powered  120vac outlets and standard USB outlets for each seat. This concrete picnic table is extremely robust and resilient to weather conditions and vandalism.

Compatible with ShadeCharger.net to enable pay-per-use charging and wifi options.

Features

  • A solar powered charging table with 120v receptacles and USB outlets
  • A powerful 1kW DC solar array and 1.5kWhr lithium battery bank
  • Architectural design, and a fully engineered commercial grade structure
  • Supports up to 75-150 hand held mobile device charges/day (typical use)
  • Supports charging for tablets, laptops, cameras, and other electronic devices
  • Attractive non-glare LED table top lighting system for nighttime use
  • True off-grid solar power design that delivers dependable year round charging power even in worst case weather conditions
  • Optimized system design includes complete solar charger, battery and power inverter and standard UL listed NEMA receptacles.
  • 90mph wind speed rated self-ballasted concrete construction
  • Low maintenance with a ten to twenty year expected service life
  • Seats six comfortably with room for additional ADA compliant wheelchair seating on ends.

DIMENSIONS

  • Canopy height (high side): 8’31/2”
  • Canopy head clearance height (low side): 6’113/4”
  • Table dimensions: 92″ x 65″ x 32″‘
  • Weight: 2650lbs
  • Canopy: 6’7” W x 11’0” L

SOLAR CHARGING SYSTEM

  • Solar array capacity: 1kW DC
  • Four 120V traditional electrical receptacles
  • Eight USB charging ports
  • Battery: 3.5kWhr sealed lithium
  • Battery bank voltage: 12.0 volts DC
  • Inverter: 1500W power inverter
  • Charge controller: Lithium battery charge controller
  • Battery replacement cycle: ten years/3000 cycles (typical)
  • All electrical and structural steel components bonded to NEC compliant earth grounding electrode (ground rod)

SOLAR POWER SYSTEM

  • Design autonomy: three days with little sunlight
  • Design depth of discharge: 80%
  • Daily energy production: 5,200Whr
  • Design location: Jackson California
  • Table and bench top material and colors
  • Wifi internet option available

STRUCTURE

  • Cast reinforced concrete unit
  • Wind speed rating: 90 mph self-ballasted (no surface attachment required)
  • Durable industrial strength construction with easy to clean surfaces
  • Seats six adults comfortably on  parallel seats
  • Engineered pole mount system,  MIG welded frame and stainless steel screws

SECURITY

  • Robust ballast mount system minimizes movement
  • Additional “anti-vandal”  attachment options
  • Robust, heavy duty components; inherently vandal-proof
  • Tamper resistant hardware and fasteners

WARRANTY

  • One year warranty on installation
  • Twenty-five year warranty on solar panel power output



Options

  • Pay-per-use option for individual outlets.
  • WiFi internet connectivity coming soon.

Additional information

Weight 1813 lbs
Dimensions 60 x 48 x 48 in
